Delivery Date:
06/21/2019
Department Name:
Frason Global Co.
Department City / State:
Mexico City, Mexico
Truck Type:
Sutphen Corporation – HS #6297
WHEEL BASE: 221”
TRAVEL HEIGHT: 10’-0 ½”
TRAVEL LENGTH: 41’-0 ¼”
CHASSIS: Sutphen Monarch Heavy Duty-Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM Single Stage
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side Body, (1) 1 ½” Front Bumper
- Crosslays: (2) 2” Valve-Piping with 1 ½” Swivel
- Monitor: Elkhart 7250 Cobra EXM with SM1500E Nozzle
- 30-Gallon Foam Tank
- 500-Gallon Water Tank
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- Amdor Roll-Up Doors
- Over 192 cu. ft. Total Compartment Space
- Alco-Lite Quint Ladder Compliment (85’, 16R’, 24’ 2-Section, 35’ 3-Section & 10’F)
ADDITIONAL EQUIPMENT:
- FRC Inview Trueview Single Camera System
- Federal Q2B Siren
- 6KW Smart Power Generator
- Hannay Electric Cord Reel, 150’ (1)
- 24” Bumper Extension
- Whelen Freedom 4 Lightbar
- FRC Spectra 20K 12V LED Brow Light
