Delivery Date:
09/12/2017
Department Name:
Decatur Fire Department
Department City / State:
Decatur, AL
Truck Type:
WHEEL BASE: 221”
TRAVEL HEIGHT: 10’-0 ½”
TRAVEL LENGTH: 40’-0 ¼”
CHASSIS: Sutphen 62” extended cab with half 10” raised rood
- Four-Door, Five-Person Cab
- Front Axle and Suspension: 23,000 lbs
- Rear Axle and Suspension: 31,000 lbs
- Engine: Cummins ISL 9, 450 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2000 GPM
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (1) 1 ½” Front Bumper
- 470-Gallon Water Tank
- 30-Gallon Foam Tank
- FoamPro 2001, 2.6 GPM
BODY: Sutphen
- Stainless Steel
- Rom Roll-Up Doors
- 75 cu. ft. Total Compartment Space
- Duo-Safety Quint Ladder Compliment
- SAA-4, Left High/ Right Intermed
OPTIONAL EQUIPMENT:
- 10KW Smart Power Generator
- Hannay Electric Cord Reel, 150’
- Camera System, Safety Vision SV-CLCD0-70
- Traffic Advisor, Whelen
- Intercom System, FRC ACT 2-Station
- Monitor: TFT Y5-E11A-L Typhoon Elec w/ M-ERP-1500 Nozzle
- Pike Pole Storage Tubes (3)
- Federal Q2B
- 18” Bumper
