Delivery Date:
06/16/2021
Department Name:
City of Dalton Fire Department
Department City / State:
Dalton, GA
Truck Type:

Sutphen Corporation – HS #6928

Dealer – Williams Fire Apparatus

WHEELBASE: 232”

TRAVEL HEIGHT: 10’ – 11”

TRAVEL LENGTH: 42’ – 3”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs.
  • Rear Axle and Suspension 31,000 lbs.
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000 w/ Retarder

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Upper Left Side Body, (1) 2 ½” Front Bumper
  • Crosslay: (2) Crosslays 2” Valve-Piping 1 ½” Swivel
  • 500-Gallon Water Tank
  • 20-Gallon Foam Tank

BODY:                  Sutphen

  • Hinged Compartment Doors
  • Over 160 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Compliment: (35’ 3-Section, 28’ 2-Section, 18’ Double Hooked Roof Ladder, (2) 16’ Double Hooked Roof Ladder, (1) 10’ Folding Ladder)
  • Body: SAA-1, Left High / Right Low
  • Monitor: TFT Y4-E11A-P-01 Monsoon Elec. with Stacked Tips

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Two Cameras
  • Intercom System: FRC ACT 2-Station
  • Hannay Electric Cord Reel, 150’ (1)
  • Generator: Smart Power 10KW
  • Whelen Freedom 4 Lightbar
  • Freedom IV Mini Lightbars
  • Whelen PCP2 12V LED Brow Light
  • Whelen M9 Scene Light
