Delivery Date:
09/08/2018
Department Name:
City of Oxford Fire Department
Department City / State:
Oxford, NC
Truck Type:
WHEEL BASE: 221”
TRAVEL HEIGHT: 10’ – 0 ½”
TRAVEL LENGTH: 41’ – 0 ¼”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2000 GPM
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (1) 2 ½” Front Bumper
- Crosslay: (2) 2” Valve-Piping, 1 ½” Swivel
- Monitor: Elkhart 7250 Cobra EXM with SM1500E Nozzle
- 500-Gallon Water Tank
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- Rom Roll-Up Compartment Doors
- Body SAA-4, Left High / Right Intermed
- Duo-Safety Ladders Quint (85’, 16R’, 24’ 2-Section, 35’ 3-Section and 10’ Folding)
- 75 cu. ft. of Total Compartment Space
OPTIONAL EQUIPMENT:
- 24” Bumper Extension, 2” Raised Lid, and Full-Width, Deep Center Trough
- Safety Vision SV-CLCD0-70, Camera System
- Smart Power 8kw Generator
- Akron Cord Reel, 175’
- Federal Q2B Siren
- Pike Pole Storage Tubes (2)
- Ladder Lighting System, Rigid
- Roto-Ray Warning Light
