WHEELBASE: 221”
TRAVEL HEIGHT: 10 – 0 ½”
TRAVEL LENGTH: 41’ – 4”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins X 12, 500HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Right Side Body, (1) 2 ½” Front Bumper
- Monitor: TFT Y5-E11A-L Typhoon Electric w/ M-ERP-1500 Nozzle
- Crosslays: (2) 2” Valve-Piping w/ 1 ½” Swivel
- 500-Gallon Water Tank
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Amdor Roll-Up Compartment Doors
- Over 210 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 28’ 3-Section; 28’ 3-Section; 16’ Roof; 16’ Roof; 10’ Folding
- Body: Left High / Right Split Depth / Trans / Ladder Chute
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Intercom System: FRC ACT 2-Station
- Camera System: FRC, Inview Trueview, Two Cameras
- Hi-Viz 3-Piece 12V LED Brow Light
- Whelen Freedom 4 Lightbar
- FRC Spectra 900 Scene Light
- Whelen M9 Warning
