Delivery Date:
12/04/2024
Department Name:
City of Boynton Beach
Department City / State:
Boynton Beach, FL
Truck Type:

Dealer – South Florida Emergency Vehicles

WHEELBASE: 232”

TRAVEL HEIGHT: 10’ – 8”

TRAVEL LENGTH: 42’ – 9”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 10-Inch Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs w/ (4) 56” Leafs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 6, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side Body, (1) 1 ½” Front Bumper, 2” Plumbing
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • 470-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Akron 125 GPM w/ Flush to a Discharge Line for One Foam Tank

BODY:                 Sutphen

  • Huckbolt #304 Stainless Steel
  • Mixed Amdor Roll-Up and Hinged Compartment Doors
  • Over 220 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 14’ Roof, 24’ 2-Section & 10’ Folding
  • Body: Left High / Right Custom / Trans

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC ACT 2-Station
  • FRC Spectra 15K 12V LED Scene Light
  • Hiviz 3-Piece 12V LED Brow Light
  • Whelen Freedom 4 Lightbar
  • FRC Spectra 12V 20K Scene Light
  • FireTech LED Rear Work Lights

MONITOR:

  • Akron 3480 Stream Master2 Electric RF w/ 5178 Nozzle
