Delivery Date:
05/14/2024
Department Name:
Braxton County Office of Emergency Services
Department City / State:
Sutton, WV
Truck Type:

Dealer – Heritage Fire Equipment

WHEELBASE: 221”

TRAVEL HEIGHT: 10’ – 1”

TRAVEL LENGTH: 40’ – 10”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ a Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L9, 450 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe Left Rear, (1) 2 ½”Auxiliary Waterway
  • Monitor: Elkhart 7205 Cobra EXM w/ SM1500E Nozzle
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                 Sutphen

  • Huckbolt #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • Over 180 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 10’ Attic, 35’ 3-Section, 28 2-Section, (2) 16’, 12’
  • Body: SAA-2, Left High / Right Low / Trans Rear

ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC ACT 2-Station
  • Camera System: FRC, Inview Trueview, Single Camera
  • Whelen Freedom 4 Lightbar
  • FireTech FT-MB-30 12V LED Scene Light
  • FRC Spectra 20K 12V LED Scene Light
