Delivery Date:
09/12/2017
Department Name:
Weirton, West Virginia Fire Department
Department City / State:
Weirton, WV
Truck Type:
WHEEL BASE: 221”
TRAVEL HEIGHT: 10’- ½”
TRAVEL LENGTH: 40’- ¼”
CHASSIS: Sutphen 56” Extended Cab with half 10” raised roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension: Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension: Rear Axle and Suspension 31,000 lbs
- Engine: Cummins ISX 15, 600 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM
- Discharge: (2) 2 ½” Left, (2) 3” Right, (1) 1 ½” Right, (2) 2 ½” Front of Upper Hosebed
- 500-Gallon Water Tank
BODY: Sutphen
- Stainless Steel
- Hinged Compartment Doors
- 75 cu. ft. Total Compartment Space
- Duo-Safety Ladders, Quint
- Body SAA-4 Left High/Right Intermed
OPTIONAL EQUIPMENT:
- 10KW Smart Power Generator
- Hannay Electric Cord Reel, 150’
- Warning Lights, Whelen
- Federal Q2B
- 18” Bumper Extension
- Camera System, Intec
- Intercom System, FRC ACT 2-Station
- Monitor: Elkhart 7205 Cobra EXM w/ SM1500E Nozzle
