Delivery Date:
06/09/2022
Department Name:
Clay Fire Department
Department City / State:
Clay, NY
Truck Type:
Sutphen Corporation – HS #7152
Dealer – Vander Molen Fire Apparatus Sales and Service
WHEELBASE: 231”
TRAVEL HEIGHT: 10’ – 0 ½”
TRAVEL LENGTH: 41’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1750 GPM 6” Suction, Single Stage Pump
- Discharges: (1) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper
- Crosslays: (3) 2” Valve Piping w/ 1 ½” Swivel
- 500-Gallon Water Tank
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Hinged Compartment Doors, Painted
- Over 192 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: (2) 16’ R, 24’ 2-Section, 35’ 3-Section, (2) 10’ Folding
- Body: SAA-4, Left High / Right Intermed / Trans
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Whelen Freedom IV Lightbar
- FRC Spectra LED Brow Light
- FRC Spectra 20K 12V LED Scene Light
- Intercom System: FRC ACT 2-Station
