Delivery Date:
07/31/2020
Department Name:
Noroton Fire Department
Department City / State:
Darien, CT
Truck Type:

Sutphen Corporation – HS #6676

WHEELBASE: 236”

TRAVEL HEIGHT: 9’ – 8 ¼”

TRAVEL LENGTH: 43’ – 7 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 40,000 lbs Tandem
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:

  • No Tank
  • No Pump

BODY:                  Sutphen

  • Hinged Compartment Doors
  • 272 cu. ft. Total Compartment Space
  • Duo Safety Custom Ladder Compliment (10’ Folding; (3) 16’ Roof; (2) 20’ Roof; 28’ 2-Section; (2) 35’ 2-Section)
  • Ladder Chute
  • Body: SL100-2 – Left High / Right High Ladders Enclosed

ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless Steel, Bumper
  • Federal Q2B Siren, Grille Mount
  • 10KW Smart Power Generator
  • Hannay Electric Cord Reel, 150’ (2)
  • Camera System, Voyager 3
  • Intercom System, FRC ACT 2-Station
  • Pike Poles Storage Tubes (6)
  • Whelen Freedom 4 Lightbar
  • Whelen PFH1 12V Brow Light (2)
  • Whelen PFH2 12V LED Light
  • Whelen PFP2AC LED 120 Telescoping Scene Light
  • Whelen TAL85 Split Traffic Advisor
  • Firetech 12V Blue LED Rung Illumination Lights
  • Firetech 12V LED Aerial Spotlights



MONITOR:

  • TFT Y4-E11A-P-01 Monsoon Electric with M-ERP-1500 Nozzle
