Delivery Date:
02/15/2019
Department Name:
Montgomery County Fire/EMS
Department City / State:
Mt. Sterling, KY
Truck Type:

Sutphen Corporation – HS #6246

Dealer – Heritage Fire Equipment

WHEEL BASE: 236”

TRAVEL HEIGHT: 9 – 10 ½”

TRAVEL LENGTH: 42’ – 5 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a Flat Roof

  • Four-Door, Four-Person Cab
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 44,000 lbs
  • Engine: Cummins ISX 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS 4000

PUMP:                 Hale

  • QMAX-2000 GPM Single Stage Pump
  • Discharges: (2) 2 ½” Left, (2) 2 ½” Right
  • Monitor: Elkhart 7205 Cobra EXM w/ SM1500E Nozzle
  • 300-Gallon Water Tank
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • Hinged Compartment Doors
  • Over 244 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Compliment (119’: 14’ Combination, 16’ Roof (2), 28’ 2-Section, 35’ 3-Section & 10’ Folding)
  • Left High/ Right High Ladders Enclosed

OPTIONAL EQUIPMENT:

  • 12” Bumper Extension
  • Intec, Single Camera, Camera System
  • FRC ACT 2-Station Intercom System
  • 6 KW Smart Power Generator
  • Hannay Electric Cord Reel, 175’ (1)
  • Pike Pole Storage Tubes (3)
  • Whelen Freedom IV Lightbar
  • Federal Q2B Siren
  • Roto Ray
  • FRC Spectra 12V LED Brow Light
