Delivery Date:
04/24/2024
Department Name:
Carroll County Fire Department
Department City / State:
Carroll County, GA
Truck Type:

Dealer – Williams Fire Apparatus

WHEELBASE: 242”

TRAVEL HEIGHT: 10’ – 2”

TRAVEL LENGTH: 44’ – 2”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab with a Flat Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails, Tandem Axle – Aerial (110K PSI)
  • Front Axle and Suspension 23,000 lbs w/ (4) 56” Leafs
  • Rear Axle and Suspension 48,000 lbs
  • Engine: Cummins X 12, 525 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4500R w/ Retarder

PUMP:                 Hale

  • QMAX-2000 GPM, 6” Suction Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
  • Crosslays: (2) 2” Valve-Piping w/ 1 ½” Swivel
  • 300-Gallon Water Tank

BODY:                 Sutphen

  • Huckbolt #304 Stainless Steel
  • Hinged Compartment Doors
  • 236 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 16’, 16’, 28’ 2-Section, 35’ 3-Section & 10’ Folding
  • Body: SL100-2 Left High / Right High Ladders Enclosed

ADDITIONAL EQUIPMENT:

  • 12” Formed Steel Channel, Bumper
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC Act 2-Station
  • Camera System: FRC, Inview Trueview, Two Cameras
  • Generator: Smart Power, 6KW ER HYD
  • Hannay Electric Cord Reel, 150’ (1)
  • Hi-Viz 3-Piece 12V LED Brow Light
  • Whelen Freedom 4 72” Lightbar
  • Whelen M6V2 Red LED Warning/Corner Light
  • FireTech FT-MB-2.21-FT 12V LED Scene Light

MONITOR:

  • TFT Y5-E11A-L Typhoon Elec w/ M-ERP-1500 Nozzle
