WHEEL BASE: 185”
TRAVEL HEIGHT: 9’-10”
TRAVEL LENGTH: 31’-10”
CHASSIS: Suthpen 62” extended cab with half 10” raised roof
- Four-Door, Four-Person Cab
- Front Axle and Suspension 19,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 380 HP
- Alternator: Leece Neville, 270 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GOPM
- Discharges: (2) ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 1000-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Ladder Chute
- 222 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Scene Lights, Whelen 900 LED
- 24” Bumper
- Alco-Lite PEL-24
- Federal Q2B
- Roto-Ray
- Warning Lights, Whelen
