WHEEL BASE: 221”
TRAVEL HEIGHT: 114”
TRAVEL LENGTH: 40’-0 ¼”
CHASSIS: Sutphen 62” Extended Cab with half 10” raised roof
- Four-Door, Four-Person Cab
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM
- (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side Front of Body, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper
- 20-Gallon Foam Tank
- Elkhart Foam Supply System
- 500-Gallon Water Tank
BODY: Sutphen
- Stainless Steel
- Rom Roll-Up Doors
- 75 cu. ft. Total Compartment Space
- Ladder Chute
- SAA-4, Left High / Right Intermed / Trans
OPTIONAL EQUIPMENT:
- Zico Electric Ladder Rack
- Duo-Safety Ladders
- 8KW Harrison Generator
- Hannay Electric Cord Reel, 100’
- Intercom System, FRC ACT 2-Station
- 24” Bumper
- Pike Pole Storage Tubes
MONITORS:
- Elkhart 7205 Cobra EXM w/ SM15000E Nozzle
