Delivery Date:
04/01/2018
Department Name:
Saint Paul Fire District, NY
Department City / State:
Rochester, NY

WHEEL BASE: 187″

TRAVEL HEIGHT: 9′-3 3/4″

TRAVEL LENGTH: 30′-7 1/2″

CHASSIS:              Sutphen 73” cab with flat roof

  • Four-Door, Eight Person Cab
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 24,000 lbs.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QMAX 1500 GPM 6” Suction Single Stage
  • Discharge: 2.5” Left, 4” Right, 2.5” Right, 3” Rear Left, 5” Rear Right, 2.5” Front Bumper,
  • 500 Gallon Water Tank
  • FOAMPRO 2002, 5.0 GPM
  • Foam Tank 30 Gallon Built Into Booster Tank

BODY:                   Sutphen

  • 6 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Exhaust Tip Turned 45 Degrees Toward the Rear
  • Cup Holder in Cab
  • Special Location for Air Brake, Down Low to The Right of the Driver below Dash Console
  • 2 Pike Pole Tubes in Cab Exterior Compartments
  • Recessed Warning Light Pockets
  • Map Box Custom Design
  • Fold and Hold for Forward Facing Seats
  • Garden Hose Tank Fill Inlet
  • Adapter for 5” Storz to Cap and Chain
  • Deadlay Compartment
  • Backboard Storage Under Crosslay Cover
  • Pump Panel Light Hoods
  • Lift Gauge for Trident Primer
  • R2 Compartment Extinguisher Mounting
  • Hinge Cover Over Left Side Preconnect
  • Switches for Ladder Rack
