Delivery Date:
06/30/2020
Department Name:
Columbia Fire Department
Department City / State:
Columbia, MO
Truck Type:
Sutphen Corporation – HS #6715
WHEELBASE: 221”
TRAVEL HEIGHT: 10’ – 9 ½”
TRAVEL LENGTH: 39’ – 6”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper
- Crosslay: (2) 2” w/ 1 ½” Swivel, (1) 2 ½” w/ 2 ½” Swivel
- 500-Gallon Water Tank
BODY: Sutphen
- ROM Roll-Up Compartment Doors
- 96 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package (24’ 2-Section & 14’ Roof & (2) 10’ Folding)
- Body: Custom – Left High/Right High/Split Depth
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- 5 Bottle Compartments
- Safety Vision Camera System
- SmartPower 8KW Generator
- FRC Spectra LED Brow Light
- Whelen Freedom IV Lightbar
- Whelen M9 Scene Lights
- Whelen L31 LED Beacons
- Rigid D2 LED Spot Lights
