Sutphen Corporation – HS #6412
Dealer – Vander Molen Fire Apparatus Sales and Service
WHEEL BASE: 221”
TRAVEL HEIGHT: 10’ – 9 ½”
TRAVEL LENGTH: 39’ – 3”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a Flat Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- CSU-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe to Left Front, (1) 2 ½” Pipe Right Front, (1) 1 ½” Front Bumper,
- Monitor: Akron 3480 Stream Master2 Electric RF w/ 5178 Nozzle
- Crosslays: (3) Crosslays, 2” Valve-Piping 1 ½” Swivel
- 500-Gallon Water Tank
- 30-Gallon Foam Tank
- FoamPro 2001, 2.6 GPM
BODY: Sutphen
- Huck Bolted #304 Stainless Steel
- Hinged Compartment Doors
- 203 cu. ft. Total Compartment Space
- Alco-Lite Pumper Ladder Compliment (14’R, 24’ 2-Section & 10’F)
- Left High, Right High, Split Depth
- Ladder Chute
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel Bumper Extension
- 6KW Smart Power Generator
- Akron Electric Cord Reel, 150’ (1)
- Backboard and Pike Pole Storage Above Ground Ladders
- Federal Q2B Siren, Grille Mount
- Firetech 3-Piece 12V LED Brow Light
- Firetech 150Watt 12V LED Scene Light, Bail Mount
- Whelen Freedom 4Lightbar
- Whelen M9 12V LED Combo Warning/Scene Lights
- Whelen TAL36 Traffic Advisor
