WHEEL BASE: 221”
TRAVLE HEIGHT: 10’ 9.25”
TRAVEL LENGTH: 42’3.75”
CHASSIS: Sutphen 62” cab with 10” half raised roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension: 23,000 lbs.
- Rear Axle and Suspension: 31,000 lbs.
- Engine: Cummins ISL 9 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5
PUMP: Hale
- 2000 GPM Single Stage
- Discharge: (2) 2.5 Left, 4” Right, 2.5” Right, 2.5” Front Left of Main Hosebed, 1.5” Front Bumper, 2” Plumbing,
- 500 Gallon Water Tank
BODY: Sutphen
- 75 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Federal Q2B
- Wrap Diamond Plate 1” around edge of cab up to paint break
- Overhead Storage compartment
- Ground Ladder Mounting
- Cab Tilt System w/Air turn valve
- 24” Bumper Extension
- Generator Smart Power, 6KW HYD
