WHEEL BASE: 200”
TRAVEL HEIGHT: 9’ 5 & 7/8”
TRAVEL LENGTH: 32’-9”
CHASSIS: Sutphen 62” Cab with Flat Roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins ISL 400HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5
PUMP: Hale
- QMAX-1500 GPM 6″ Suction Single Stage Pump
- Discharge: (2) 2 ½ Left, 2 ½” Left Rear, (1) 4”, 2.5” Right, (2) 2 1/2” Valve 2 ½” Pipe Right Rear, 2 1/2” Front Left of main hose bed, 1 ½” Front Bumper, 2” Plumbing, 3” Deck Gun
- 500 Gallon Water Tank
- 30 Gallon Foam Tank built into booster tank
BODY: Sutphen
- Aluminum body
- Ladder Chute
- 234 Cu. Ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- 18” Steel Channel Bumper with painted Scorpion on top
- ZIAMATIC SAC-44 FOLDING WHEEL CHOCKS MTD W/ SQCH-44H HOLDERS (PAIR)
- Back up Camera
