Delivery Date:
05/01/2018
Department Name:
Resort Bear Creek Fire Department, MI
Department City / State:
Petoskey, MI

WHEEL BASE: 215”

TRAVEL HEIGHT: 9’ 10”

TRAVEL LENGTH: 34′ 4”

CHASSIS:              Sutphen 73” Cab with 10” half raised roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension: 20,000 Lbs.
  • Rear Axle and Suspension: 31,000 Lbs.
  • Engine: Cummins L 9 400HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QMAX-1500 Single Stage
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Left Rear, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
  • 1000 Gallon Water Tank

BODY:                   Sutphen

  • 266 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Pump Primer 2 Trident Auto Air Primer
  • Gauge, Water Level, Class 1 Intelli-Tank 40
  • Support Bar for Rear Hosecover Removable
  • Full Step the Length of the Hose Bed
  • 10 Year Paint Warranty
  • Officer’s Side Speedometer
  • Secondary Camera Monitor, Safety Vision, Rainproof
  • Intake Pressure Control Akron 53 Style Intake Relief
  • 5” Right Rear Suction w/Hale Miv Valve, Electric
  • Two Safety Bar, Mansaver, with Vinyl Cover
