Delivery Date:
05/01/2018
Department Name:
Resort Bear Creek Fire Department, MI
Department City / State:
Petoskey, MI
Truck Type:
WHEEL BASE: 215”
TRAVEL HEIGHT: 9’ 10”
TRAVEL LENGTH: 34′ 4”
CHASSIS: Sutphen 73” Cab with 10” half raised roof
- Four-Door, Five-Person Cab
- Front Axle and Suspension: 20,000 Lbs.
- Rear Axle and Suspension: 31,000 Lbs.
- Engine: Cummins L 9 400HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5
PUMP: Hale
- QMAX-1500 Single Stage
- Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Left Rear, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
- 1000 Gallon Water Tank
BODY: Sutphen
- 266 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Pump Primer 2 Trident Auto Air Primer
- Gauge, Water Level, Class 1 Intelli-Tank 40
- Support Bar for Rear Hosecover Removable
- Full Step the Length of the Hose Bed
- 10 Year Paint Warranty
- Officer’s Side Speedometer
- Secondary Camera Monitor, Safety Vision, Rainproof
- Intake Pressure Control Akron 53 Style Intake Relief
- 5” Right Rear Suction w/Hale Miv Valve, Electric
- Two Safety Bar, Mansaver, with Vinyl Cover
