Delivery Date:
05/01/2018
Department Name:
Pell City Fire Department
Department City / State:
Pell City, AL

WHEEL BASE: 185”

TRAVEL HEIGHT: 9’ 8” ±2”

TRAVEL LENGTH: 31′ 7”

CHASSIS:              Sutphen 62” Cab with 10” half raised roof

  • Four-Door, Four-Person Cab
  • Front Axle and Suspension: 18,000 Lbs.
  • Rear Axle and Suspension: 24,000 Lbs.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QFLO-1250 Single Stage
  • Discharge: (2) 2.5” Left, (2) 2.5” Right, 2.5” Left Rear, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun

BODY:                   Sutphen

  • 234 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Central Location For Air Tank Drains
  • Crew Seat 3 EMS Compartment, Forward Facing, w/Rollup Doors
  • Camera System, Voyager 3, Split Screen
  • Intercom System, Wired, Firecom 5-Position
  • Central Location For Air Tank Drains
  • Pressure Control Hale QD Relief Valve
  • Intake Pressure Control Akron 59
  • Hand Throttle On Panel, Class 1 Twister
  • Step at Pump Panel for Operator on each side
  • LED Light Strip Across the Front of Hose Bed Wired to Ground Light Circuit
  • 12V Wiring for Relay and Switch For Tele-Lights on Back of Cab
  • Chevrons on Interior Door Panels of Compartment
  • Streamlight Litebox LED Hand lights, Mounted
  • Voyager 3 Camera System Split Screen
