Delivery Date:
04/01/2018
Department Name:
Peachtree City Fire Department
Department City / State:
Peachtree City, GA

WHEEL BASE: 197”

TRAVEL HEIGHT: 10′-2″±2″

TRAVEL LENGTH: 33′-1″

CHASSIS:              Sutphen 56” cab with 10” half raised roof

  • Four-Door, Four Person Cab
  • Front Axle and Suspension: 23,000 lbs.
  • Rear Axle and Suspension: 24,000 lbs.
  • Engine: Cummins ISX 12 425HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QMAX-1500 GPM 6” Suction Single Stage Pump
  • Discharge: (2) 2.5” Left, 4” Right, 2.5” Right, (2) 2.5” Front/Left of Main Hosebed, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
  • 750 Gallon Water Tank

BODY:                   Sutphen

  • 257 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Line Stepwell of Cab with Treadplate
  • Light in FDNY Glove Box
  • CENTECH 2,000W/4,000W Peak Inverter
  • (2) Poly Trays for Speedlay
  • Three LED Hooded Light Bars on each Pump Panel
  • Pump Hour Meter on Pump Panel
  • Lowered Hosebed 48” from Tailboard
  • (4) 8” Handrail, Knurled Stainless Steel
  • Light Tower, Command Light, SL442A-W2 LED W/STROBE
  • (4) Pike Pole Storage Tubes on Drivers Side
