Delivery Date:
02/19/2020
Department Name:
North Ridgeville Fire and Rescue, Ohio
Department City / State:
North Ridgeville, Ohio
Truck Type:
WHEEL BASE: 253”
TRAVEL HEIGHT: 9’ – 11 ¼”
TRAVEL LENGTH: 45’ – 6 ¾”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 52,000 lbs Tandem
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM, 6” Suction Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front Bumper
- Crosslay: (2) 2” w/ 1 ½” Swivel
- 600-Gallon Water Tank
BODY: Sutphen
- ROM Roll-Up Compartment Doors
- 58 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package (aerials 115’ 14’, 16’, 16’, 24’ 2-Section, 35’ 3-section & 10’F)
- Ladder Chutes
- Body: SL100-1 – left high / right low
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Channel, Bumper
- Federal Q2B Siren, Grille Mount
- Firetech 12V LED Brow Light
- Whelen Freedom 4 Lightbar
- FRC Spectra 15K 12V LED Scene Lights
- FRC Spectra 12V LED Scene Lights
