WHEEL BASE: 197”
TRAVEL LENGTH: 32’ 1”
CHASSIS: Sutphen 73” Cab with 10” half raised roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension: 20,000 Lbs.
- Rear Axle and Suspension: 27,000 Lbs.
- Engine: Cummins ISL 9 400HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5
PUMP: Hale
- CSU-2000 GPM Single Stage
- Discharge: (2) 2.5 Left, 3” Right, 2.5” Right, 2.5” Valve, 2.5” Pipe Right Rear, 2.5” Blitz Fire on Rear, 2.5” Front/Left of Main Hosebed
- 750 Gallon Water Tank
- 40 Gallon Foam Tank built into Booster Tank
BODY: Sutphen
- 180.4 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Stream Shaper & Stacked Tips
- Blue Backlit Gauge Upgrade
- On-Scene Solutions LED Strips
- Waterous overheat alarm system
- M9 Door Activation
- Whelen Backup Circuit
- Mounting Provision
- Additional Plug into Rear of Cab
- Shut off Windshield Wipers and Headlights when Park Brake Activated
- ISX Grille
- Customer Opticom to Cab Roof Mounting Location Driver Side Inboard of the Front Scene Lights East to Install
- Top Front of Bumper Coating Scorpion
- Secondary Switch Panels over Officer
