WHEEL BASE: 231”
TRAVEL HEIGHT: 9’ 7.5”
TRAVEL LENGTH: 32’ 7.5”
CHASSIS: Sutphen Cab with half raised roof
- Four-Door, Two-Person Cab
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 46,000 lbs.
- Engine: Cummins L9 380 HP
- Alternator: Leece Neville 320 AMP
PUMP: Hale
- QFLO-1250 Single Stage
- Discharge: (2) 2.5” Left, 3” Right, 2.5” Left Rear, 3” Deck Gun,
- 3000 Gallon Water Tank
BODY: Sutphen
- Aluminum
- 96 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Rear Differential Lock on Chassis
- EQ2B Wired to Steering Wheel Switch for City Horn/ EQ2B
- EQ2B Officer’s Foot Pedal
- Pump Panel Heater Shutoff Valves Standard near Heater.
- Water Level Gauge Class 1 ITL 40
- 4’ Pike Pole Mount
- Vertical Divider for SCBA Brackets Shall be on Slide-Out In
- Painted Stainless Body
- (2) Hosebed Dividers
