Delivery Date:
02/13/2020
Department Name:
McLeansville Fire Department
Department City / State:
McLeansville, NC

WHEEL BASE: 185”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 31’

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • XS QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (1) 2 ½” w/ Swivel & Poly Lift-Out Tray
  • Speedlay: (2) 2” w/ Swivel & Poly Lift-Out Tray
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • Amdor Roll-Up Compartment Doors
  • 270 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder Chutes
  • Body: G2 – Alum 40/51 Ladder Chute

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System, FRC, Inview Trueview
  • Air Bottle Compartments (4)
  • Firetech LED Brow Light
  • Whelen Freedom LED Lightbar
  • Whelen PFH2 12V LED Scene Lights
