Delivery Date:
12/01/2017
Department Name:
Mashantucket Fire Department
Department City / State:
Mashantucket, CT

WHEEL BASE:  196″

TRAVEL HEIGHT: 9′-10″

TRAVEL LENGTH: 32′-9″

CHASSIS:              Sutphen 73” extended cab with half 10” raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 20,000 Lbs.
  • Rear Axle and Suspension: 27,000 Lbs.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QMAX-1500 GPM Single Stage
  • Discharge: (2) 2.5″ Left, 2.5″ Left Rear, 3″ Right, 2.5″ Right, 2.5″ Right Rear, 3” Deck Gun
  • 1000 Gallon Water Tank
  • 30 Gallon Foam Tank built into Booster Tank

BODY:                   Sutphen

  • Aluminum
  • 266 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24

OPTIONAL EQUIPMENT:

  • Federal Q2B
  • 24” Bumper Extension
  • Camera System, Safety Vision SV-CLCDO-70
  • Back up camera monitor
  • Ziamatic SAC-44 Folding Wheel Chocks MTD with SQCH-44H Holders.
  • Crew seat compartment flip down door

Ladder chute through water tank above A1 compartment
