Delivery Date:
09/12/2017
Department Name:
Kennedy Township VFD
Department City / State:
McKees Rocks, PA
Truck Type:
Custom Pumper – PA – 05 Body
WHEEL BASE: 245”
TRAVEL HEIGHT: 116”
TRAVEL LENGTH: 436 ½”
CHASSIS: Sutphen 73” extended cab with half 10” raised roof
- Four-Door, Eight-Person Cab
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2250 GPM
- Discharge: (1) 3” Left, (1) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front Left, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 20-Gallon Foam Tank
- Akron 125 GPM 3126 By-Pass System w/ Flush to a Discharge Line for foam tank
- 900-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Rom Roll-up Doors
- 307 cu. ft. Total Compartment Space
- Alco-Lite PEL-24
OPTIONAL EQUIPMENT:
- 20KW Harrison Generator
- Hannay Electric Cord Reel, 200’ (2)
- 18” Bumper
- Rear Access Ladder
- Ziamatic 3097 Quick-Lift Electric Ladder Rack
- Traffic Advisor, Whelen
- Roto-Ray Warning Light
- Scene Lights, Whelen
- Rear-View Backup Camera
