Delivery Date:
05/01/2018
Department Name:
Jefferson Township Fire Department
Department City / State:
Goshen, IN

WHEEL BASE: 226”

TRAVEL HEIGHT: 9’ 10”

TRAVEL LENGTH: 35′ 3”

CHASSIS:              Sutphen 73” Cab with 10” half raised roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension: 20,000 Lbs.
  • Rear Axle and Suspension: 27,000 Lbs.
  • Engine: Cummins L 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QFLO-1250 GPM Single Stage
  • Discharge: (2) 2.5” Left, (2) 2.5” Right, 2.5” Left Rear, 2.5” Right Rear, 1.5” Front Bumper, 2” Plumbing,
  • 1000 Gallon Water Tank

BODY:                   Sutphen

  • 270 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Full Step Underneath Hosebed
  • Triple Bottle Wheelwell Storage
  • Mars Light in Grille
  • Cab Pump Shift, Electronic Shift with Interlock
  • All Valves are Elkhart Brass
  • Sentry Pressure Governor with Twister Knob
