Delivery Date:
11/20/2020
Department Name:
Chatham Township Fire Department
Department City / State:
Chatham, NJ
Truck Type:

Sutphen Corporation – HS #6633

Dealer – Blaze Emergency Equipment

WHEELBASE: 227”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 34’ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 13” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4500

PUMP:                 Hale

  • 300 GPM APS PTO Pumper Side Kick Design
  • Discharges: (1) 2 ½” Left, (1) 2 ½” Front Bumper
  • 300-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: FoamPro 2002, 5.0 GPM

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • Over 560 Cu. Ft. Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Body: PA-16 Res 56/53 Ladder Under Hosebed and Double Hatch

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Hannay Electric Cord Reel, 150’ (2)
  • Camera System: Brigade, 360 Camera System
  • Generator: Harrison 10KW HYD
  • Whelen 72” Freedom Lightbar
  • FR Spectra Brow Lights (2)
  • FR Spectra Scene Lights (8)
  • Will-Burt NS VRT 920 FRC Spectra 240V LED 17ft. Telescoping Light Tower
