Delivery Date:
08/12/2018
Department Name:
Hamilton Volunteer Fire Department
Department City / State:
Hamilton, Indiana
Truck Type:
WHEEL BASE: 226”
TRAVEL HEIGHT: 9’-10”
TRAVEL LENGTH: 35’-1”
CHASSIS: Sutphen 73” cab with 10” half raised roof
- Four-Door, Five-Person Cab
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Waterous
- CSU-1500 Single Stage
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 1000-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Rom Roll-Up Doors
- 222 cu. ft. Total Compartment Space
- Ladder Chute
OPTIONAL EQUIPMENT:
- 6KW Smart Power Generator
- Hannay Electric Cord Reel, 150’
- Federal Q2B
- Alco-Lite PEL-24
- 18” Bumper
