Delivery Date:
12/01/2017
Department Name:
Gwinnett County Fire/Emergency Services
Department City / State:
Lawrenceville, GA
Truck Type:
WHEEL BASE: 221”
TRAVEL HEIGHT: 9’ 6”
TRAVEL LENGTH: 42′-11″
CHASSIS: Sutphen 62” extended cab with half 10” raised roof
- Four-Door, Five-Person Cab
- Front Axle and Suspension: 23,000 Lbs.
- Rear Axle and Suspension: 31,000 Lbs.
- Engine: Cummins ISX 12 500HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison GEN 5
PUMP: Hale
- QMAX-1500 GPM 6″ Suction Single Stage
- Discharge: (2) 2.5″ Left, 4″ Right, 2.5″ Right, 2.5″ Upper Left Side Body, 2.5″ Valve, 2.5″Pipe to Left Rear, 1.5″ Front Bumper, 2″ Plumbing,
- 400 Gallon Water Tank
BODY: Sutphen
- 95 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Federal Q2B
- Smart Power Generator 10kw
- Hannay ECR 1616-17-18 Reel W/200’ 10/3
- Ziamatic SAC-44 Folding Wheel Chocks MTD W/SQCH 44H Holders
- Intercom System, FRC Act 2-station
- Federal Signal Camera (Multiplex)
