WHEEL BASE: 199”
TRAVEL HEIGHT: 10’
TRAVEL LENGTH: 32’ – 9”
CHASSIS: Sutphen 73” extended cab with half 10” raised roof
- Four-Door, Five-Person Cab
- Front Axle and Suspension: 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS4000R
PUMP: Hale
- QMAX-1500 GPM
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 4” Deck Gun
- 750-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Fully Enclosed Ladder Chute
- 236 cu. ft. total compartment space
- Rom Roll-Up Doors
OPTIONAL EQUIPMENT:
- Camera System, Federal Signal
- 18” Bumper
- Federal Q2B
- Intercom System, David Clark, 5 Position – Dual Interface
- Roto – Ray Warning Light
- Pike Pole Storage Tube
