Delivery Date:
12/01/2017
Department Name:
Grosse Point Park Fire Department
Department City / State:
Grosse Point Park, MI

WHEEL BASE: 196″

TRAVEL HEIGHT: 9′-8″ ±2″

TRAVEL LENGTH: 33′

CHASSIS:              Sutphen 73” extended cab with half 10” raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 20,000 Lb.
  • Rear Axle and Suspension: 27,000 Lb.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM Single Stage
  • Discharge: (2) 2.5″ Left, 3″ Right, 2.5″ Right, 2.5″ Left Rear, 2.5″ Right Rear, 1.5″ Front Bumper, 2″ Plumbing, 3” Deck Gun
  • 1000 Gallon Water Tank w/30 Gallon Foam Cell

BODY:                   Sutphen

  • Aluminum
  • 222 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24

OPTIONAL EQUIPMENT:

  • Federal Q2B
  • 24” Bumper Extension
  • Ziamatic SAC-44 Folding wheel Chocks
  • Remote mount primer
  • Locking Latches for crew seat compartment, Side doors (locks to match officer seat rise)
