Delivery Date:
06/01/2018
Department Name:
Greeneville Fire Department
Department City / State:
Greeneville, TN

WHEEL BASE: 196”

TRAVEL HEIGHT: 9′-10″

TRAVEL LENGTH: 32′-3″

CHASSIS:              Sutphen 73” cab with 10” half raised roof

  • Four-Door, Five Person Cab
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • XS QMAX-1500 GPM Single Stage
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Left Rear, 2.5” Front Bumper, 2.5” Plumbing, 3” Deck Gun
  • 1000 Gallon Water Tank

BODY:                   Sutphen

  • 270 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Water Level Gauge FRC TANKVISION Pro 300
  • 120 V Outlets
  • Hosebed Cover Cargo Net For Hosebed
  • 2 Hand Rails at Rear of Body, One Each Side above 900 Series Warning Lights
  • Dual Coffin Boxes
  • Stokes Storage
  • Paint Area around Rear Wheels
  • Alcoa Durabright Al Wheels
  • Mount Customer Antenna
  • Stainless on Rear of Cab
  • Setcom Headsets
  • 12V Power and Gound Whip
  • Pressure Control FRC in Control 400
  • Cover Crosslay/Speedlay Cargo Net Cover
