WHEEL BASE: 173”
TRAVEL HEIGHT: 9’ 10”
TRAVEL LENGTH: 30’ 1”
CHASSIS: Sutphen 62” cab with half raised roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension: 18,000 lbs.
- Rear Axle and Suspension: 24,000 lbs.
- Engine: Cummins L9 400HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5
PUMP: Hale
- XS QMAX-1500 GPM
- Discharge: (2) 2.5” Left, 2.5” Right, 4” LDH, 2.5” Front/Left of Main Hosebed, 2.5” Front/Right of Main Hosebed, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
- 500 Gallon Water Tank
BODY: Sutphen
- 2 cu. ft. Total Compartment Space
OPTIONAL EQUIPMENT:
- Pactrac
- 120 V Power Shoreline All on Transfer Switch with 5-20 House Hold Outlets
- Additional Transverse Compartment for Stokes Basket Storage in Body
- No cover over the Stokes in A1.
- Special Suction Hose (2) 12’-6” Lengths of Kochek 6” Suction Hose
- High Rise Pack Hose Trough
- Pump Panel Controls for Scene Lights
