Delivery Date:
02/01/2018
Department Name:
East Glenville Fire Department
Department City / State:
Glenville, NY

WHEEL BASE:  219″

TRAVEL HEIGHT: 10′-1″±2″

TRAVEL LENGTH: 35′-6″

CHASSIS:              Sutphen 73” Cab with 15” half raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 23,000 Lbs.
  • Rear Axle and Suspension: 31,000 Lbs.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:

  • QMAX-1500 6” Suction Single Stage Pump
  • Discharge: (2) 2.5” Left, 4” Right, 2.5” Right, 2.5” Valve 2.5” Pipe to Left Rear, 2.5” Valve 2.5” Pipe Center Rear, 1.5” Front Bumper, 2” Plumbing
  • 750-Gallon Water Tank

OPTIONAL EQUIPMENT:

  • Harrison 10 KW HYD Generator
  • Scene Lights, Whelen
  • Ziamatic saw Blade Holder
  • Federal Q2B
  • Ziamatic SAC-44 Folding Wheel Chocks
  • Rear access ladder, stainless steel, custom fire taller for rescue body.
  • Ladders mounted under hose bed
  • Exterior compartment driver’s side to be 28” deep
