Delivery Date:
08/12/2018
Department Name:
Dearborn Fire Department
Department City / State:
Dearborn, MI

WHEEL BASE: 185”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 32’ – 1”

CHASSIS:             Sutphen 62” extended cab with half 10” raised roof

  • Four-Door, Four-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L9, 450 HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • 500-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Hale Foamlogix 2.1 tank and Intelli-Tank Gauge

BODY:                  Sutphen

  • Aluminum
  • Ladder Chute
  • 3 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24

OPTIONAL EQUIPMENT:

  • Whelen Traffic Advisor
  • 6KW Smart Power Generator
  • Federal Q2B
  • Camera System, Voyager 3, Split Screen
  • Hannay Electric Cord Reel, 150’
  • 24” Bumper
