Delivery Date:
12/15/2021
Department Name:
Union Township Fire Co.
Department City / State:
Winfield, PA

Sutphen Corporation – HS #6944

Dealer – Signal 1 Fire Equipment

WHEELBASE: 208 ½”

TRAVEL HEIGHT: 10’ – 3”

TRAVEL LENGTH: 34’ – 3”

CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10 ½” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Domex Double Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 48,000 lbs
  • Engine: Cummins X 12 500HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS 4500

PUMP:                 Hale

  • QMAX-1500 GPM Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (2) 2 ½” Left Rear, (1) 3” Deck Gun
  • Crosslays: (3) 2” w/ 1 ½” Swivel
  • 2,500-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll Up Compartment Doors
  • Over 148 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Compliment: 28’ 2-section, 16’ Roof & 10’ Folding
  • Body: SWT-04A WetSide Tanker Tandem, Pump Module



ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless Steel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview TrueView, Single Camera
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Portable Tank, 2,500 Gallon
  • Whelen 72” Freedom LED Lightbar
  • Whelen 36” Traffic Advisor
  • FRC Spectra Brow Light
  • FR Spectra Scene Lights
  • Whelen L31 Beacons
