Delivery Date:
02/25/2022
Department Name:
Penn Township Fire Department
Department City / State:
Mishawaka, IN
Truck Type:
Sutphen Corporation – HS #6995
Dealer – Herb Fire
WHEELBASE: 223”
TRAVEL HEIGHT: 9’ -10”
TRAVEL LENGTH: 36’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 40,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS 3000
PUMP: Waterous
- CSU-1500 GPM Single Stage Pump
- Discharges: (1) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe to Left Rear, (1) 2 ½” Pipe Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (2) 2” Valve-Piping 1 ½” Swivel
- 2,000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Hinged Compartment Doors
- Over 165 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Ladder Chute
- Body: TA-05 Tanker 56/53 High/High – Ladder Rack
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Single Camera
- Newton 10” Kwik Dump Electric
- Whelen 72” Freedom Lightbar
- Whelen 21” Freedom Lightbars
- Whelen M9 Scene Lights
- Whelen 36” Traffic Advisor
- Whelen Tele Lights
