Delivery Date:
08/30/2022
Department Name:
Mt. Solon Volunteer Fire Rescue
Department City / State:
Mt. Solon, VA
Truck Type:
Sutphen Corporation – HS #7059
WHEELBASE: 201”
TRAVEL HEIGHT: 10’ – 4”
TRAVEL LENGTH: 32’ – 5 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 48,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (2) 2” w/ 1 ½” Swivel, (1) 2 ½” Crosslay
- 2,500-Gallon Water Tank
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Hinged Compartment Doors
- Over 130 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 900A 24’ 2-section & 775A 14’ Roof & 10’ Folding
- Body: SWT-04A STS Wetside Tanker Tandem
ADDITIONAL EQUIPMENT:
- 12” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Ziamatic Quic-Lift Electric Ladder Rack
- Newton 10” Kwik Dump Electric
- Roto-Ray Warning Light
- Whelen 72” Freedom Lightbar
- Whelen 21” Mini Freedoms
- FR Spectra Brow Light
- FR Spectra Tele Lights
- FR Spectra Scene Lights
