Delivery Date:
05/14/2024
Department Name:
Montrose Township Fire Department
Department City / State:
Montrose Township, MI
Truck Type:
Dealer – Apollo Fire Apparatus Sales and Service
WHEELBASE: 233”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 39’ – 0 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Cab w/ 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 40,000 lbs
- Engine: Cummins X 12, 500HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-XS-2000 GPM 6” Suction, Single Stage Pump
- Discharges: (1) 4” Left, (1) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 3” Deck Gun
- Speedlay: (3) 1 ½”
- Crosslays: (1) 2 ½”
- 2,500-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll Up Compartment Doors, Painted
- 154 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 1200A 28’ 2-Section & 775A 14’ Roof & 10’ Folding
- Body: TA-03 Tanker 31/53 High/High – Ladder Rack
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Channel, Painted
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade, Backeye 360 Camera System
- Roto-Ray Warning Light
- FireTech 3-Piece 72” LED Brow Light
- Whelen Freedom IV 72” LED Light Bar
- Whelen 600 Warning Light
- FireTech Guardian Elite Scene Light 20K
