Delivery Date:
08/09/2023
Department Name:
Ludwigs Corner FC #1
Department City / State:
Glennmoore, PA
Truck Type:
Dealer – Signal 1 Fire Equipment
WHEELBASE: 217”
TRAVEL HEIGHT: 10’ – 6”
TRAVEL LENGTH: 36′ – 4”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” cab with 15” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension: 23,000 lbs.
- Rear Axle and Suspension: 52,000 lbs.
- Engine: Cummins X 12, 500HP
- Alternator: C.E. Niehoff 360 AMP
- Transmission: Allison Gen 5, EVS4500
PUMP: Hale
- QMAX-XS-2000 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Pipe to Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (2) 1 ½” & (1) 2 ½” w/ Swivels
- 3500-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System: FoamPro 2002, 5.0 GPM
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll-Up Compartment Doors
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- 174 cu. ft. Total Compartment Space
- Body: TA-05 Alum Tanker High/High – Ladder Rack
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade, Single Camera
- Zico Extended Down Ladder Rack
- Roto-Ray Warning Light
- FireTech 72” Brow Light
- Whelen 72” Freedom Lightbar with Opticom
- FireTech Recessed Scene Lights
