Delivery Date:
08/21/2024
Department Name:
Geneseo Fire Department
Department City / State:
Geneseo, NY
Truck Type:
Dealer – Herb Fire
WHEELBASE: 215”
TRAVEL HEIGHT: 11’ – 2”
TRAVEL LENGTH: 34’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 10-Inch Raised Roof
- Four-Door, Seven-Person Cab
- 10” Double Domex Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L9, 450 HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 3” Right, (2) 3” Front/Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Monitor: TFT XFC-52 Crossfire w/ Safety Flow, w/ Quad Stack Tops, Stream Shaper & Master Stream Nozzle
- Crosslays: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
- 1,600-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- Over 155 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL3-35 35’ 3-Section & PRL-14 14’ Roof & 10’ Folding
- Body: TA-01 Tanker 56/53 High/Low – Ladder Chute
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Newton Dump Valve
- Camera System: FRC, Inview Trueview, Two Cameras
- Whelen 72” Freedom Lightbar
- FRC Spectra 20K Scene Light
- FRC Spectra Tele Lights
