Delivery Date:
02/14/2020
Department Name:
Johnston Township Fire Department
Department City / State:
Farmdale, OH

WHEELBASE: 202”

TRAVEL HEIGHT: 9’ – 4 ¾”

TRAVEL LENGTH: 33’ – 5”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 44,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QFLO-1250 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 2500-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • 7 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Body: SWT-04A

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • FRC Inview Camera
  • Air Bottle Compartments (1)
  • FR Spectra Brow Light
  • Whelen 600 Warning Light
  • Whelen Freedom 72” Lightbar
  • Whelen M6 Scene Lights
