Delivery Date:
12/10/2024
Department Name:
Gardner Fire Department
Department City / State:
Gardner, MA
Truck Type:
Dealer: MES-Shipman’s Fire
WHEELBASE: 179”
TRAVEL HEIGHT: 10’ – 10”
TRAVEL LENGTH: 30’ – 6 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 56” Cab with a 20” Raised Roof
- Four-Door, Four- Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 18,000 lbs w/ (3) 54” Leafs
- Rear Axle and Suspension 24,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: No Pump, No Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll Up Compartment Doors
- Duo Safety: 12’ Attic Ladder, Fresno 701, Mounted
- Nearly 700 cu ft. Total Compartment Space
- Body: RA-18 18’ Aluminum, Walk Around, Single Axle, w/ Double Hatch Compartments
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Two Cameras (Wired)
- Generator: Harrion 15 KW PTO
- Hannay Electric Cord Reel, 150’ (2)
- FireTech 3-Piece 72” LED Brow Light
- Whelen Freedom IV 72” LED Light Bar
- Command Light Light Tower CL802A
- Opticom Mounted in Lightbar
