Department Name:
Youngstown Whitney VFD
Department City / State:
Youngstown, PA
Truck Type:
Dealer: FAST of the Allegheny Mountains
WHEELBASE: 242”
TRAVEL HEIGHT: 10’ – 2 3/8”
TRAVEL LENGTH: 35’ – 4 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 15” Raised Roof
- Four-Door, Eight-Person Cab
- 10” Double Domex Frame Rails, Single Axle (110K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins X 15 600HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM, 6” Suction Single Stage Pump
- Discharges: (1) 3” Left, (1) 2 ½” Left, (1) 4” Right, (1) 3” Right, (1) 2 ½” Pipe to Left Rear, (1) 3” Pipe to Right Rear, (1) 2 ½” Front/Left of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlay: (2) 1 ½”
- Crosslay: (1) 1 ½” and (1) 2 ½”
- 750-Gallon Water Tank
- 25-Gallon Foam Tank
- Foam System: Hale SmartFoam 5.0
BODY: Sutphen
- Huckbolted #304 Stainless Steel
- Amdor Roll Up Compartment Doors
- Over 315 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 900A 24’ 2-Section; 775A 14’ Roof & 10’ Folding
- Body: PS-04 RES 40/47 Electric Ladder Rack
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Two Cameras
- Hannay Electric Cord Reel, 200’ (1)
- Generator: Smart Power, 6KW HYD
- Roto-Ray Warning Light
- Whelen Freedom IV 72” Freedom Light Bar
- Whelen 900 Warning Lights
- FRC Spectra Brow Lights
- FireTech Guardian Elite Scene Lights
- FRC Tripod Lights
MONITOR:
- Monitor: TFT XFC-42 Crossfire w/ Safety Flow w/ Quad Stack Tips
