Delivery Date:
09/20/2023
Department Name:
Woodville Township Fire Department
Department City / State:
Woodville Township, Ohio

Dealer –  Herb Fire

WHEELBASE: 196”

TRAVEL HEIGHT: 10’ – 3”

TRAVEL LENGTH: 32′ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with a 15” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-XS-1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front/Left of Main Hosebed, (1) 1 ½” Front Bumper, 3” Deck Gun
  • Crosslays: (1) 2 ½” & Speedlays, (2) 2” w/ Swivels & Poly Lift-Out Trays
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Hale Smartfom 2.1 A

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • 294 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’ 2-Sec & PRL-14 14’ Roof & 10’ Folding
  • Body: G9 – Alum 40/51 Ladders Through Tank

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Hannay Electric Cord Reel, 150’ (1)
  • Generator: Smart Power, 6KW TM HYD
  • FRC Spectra Brow Light
  • Whelen Freedom LED Lightbar
  • FRC Spectra LED Scene
  • Whelen M9 Red LEDS
