Delivery Date:
02/21/2020
Department Name:
Winston-Salem Fire Department
Department City / State:
Winston-Salem, NC
Truck Type:
WHEEL BASE: 199”
TRAVEL HEIGHT: 9’ – 5”
TRAVEL LENGTH: 33’ – 6”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab
- Four-Door, five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2” right/front (1) 2 ½” Right Rear, (1) 2 ½” left rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (1) 2 ½” w/ 2 ½” Swivel, (2) 2” w/ 1 ½” Swivel
- 650-Gallon Water Tank
BODY: Sutphen
- Amdor Roll-Up Compartment Doors
- 234 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
- Ladder Chutes
- Body: PA-12 RES 43/53 Ladder Chute
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel bumper
- Federal Q2B Siren, Grille Mount
- Rear View Camera
- Air Bottle rack (7)
- Whelen PFH2 12V LED Brow Light
- Whelen Freedom LED Lightbar
- FRC Spectra 900 12V LED Scene Lights
