Delivery Date:
10/17/2017
Department Name:
Palm Beach County Fire Rescue
Department City / State:
West Palm Beach, FL

WHEEL BASE: 208”

TRAVEL HEIGHT: 10’-2”

TRAVEL LENGTH: 34’

CHASSIS:              Sutphen 62” extended cab with half 10” raised roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins ISL 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM
  • Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • 30-Gallon Foam Tank
  • Foamlogix 5.0
  • 750-Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • Hinged Compartment Doors
  • 257 cu. ft. total compartment space
  • Alco-Lite PEL-24

OPTIONAL EQUIPMENT:

  • Hannay Booster Reel w/ 150’
  • Combo Scene/Warning Light, Whelen
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Rear Vision Camera
  • Federal Q2B
  • 24” Bumper
  • Folding Ladder/ Pike Pole Storage Compt.
  • Backboard Storage Compartment
